Micro Fixture

Our most popular model, Perfect Fit Micro Fixtures are made in the USA by Northwest LED Lighting. Just 3/8″ tall X 11/16″ wide, these fixtures are ideal for under-cabinet, in-cabinet, cove and toe kick lighting. Available with Frosted, Prismatic, and Focus diffuser lens options in lengths from 4″ to 16 feet in many brightness and color temperature options. 3M mounting tape standard, mounting clips (fixed and rotating) optional.

Downloads

Product Options

Brightness Specifications

Brightness Watts/ft. Lumens LEDs/ft. Best Uses
Soft 1.5 130 Lumens/Ft. 18 Toe kick, small cabinet interior lighting
Medium Bright 2.9 260 Lumens/Ft. 36 In cabinet & display lighting where fixtures are visible
Bright 4 350 Lumens/Ft. 18 Under cabinet, task, pantry
Extra Bright 4.4 400 Lumens/Ft. 36 Under cabinet, task, pantry
Ultra Bright 5.5 763 Lumens/Ft. 39 Task, Wall Wash, Very Bright Under Cabinet
Warm Dim 3.9 275 Lumens/Ft. Decorative, Pendant, Vanities
RGB 4.4 Color adjustable 18 Color Adjustable
RGBW 5.1 180 18 Color adjustable plus White Light

Color Temperature Options

Temperature Traditional Equivalent Description
2700-1800 "Warm Dim" Dimmed Incandescent Warm Dim - 2700k dims to 1800k
2400 k Dimmed Incandescent Very Warm White
2700 k Incandescent White Warm White
3000 k Halogen White White
3500 K White White
4000 k Natural White Cool White

Lens Options

Lens Description
Frosted Produces a softer, slightly warmer diffused light and are preferred with reflective surfaces to minimize glare and reflection.
Prismatic Produces a brighter, slightly whiter light and are preferred where maximum light output is desired and the fixture is hidden from normal view.
Focus Narrow focus lens for wall wash / grazing and sign lighting.
Black Appears black when not lit, best for areas where de-emphasizing the lens is desired (reduces light output).

Finish Options

Finish
Silver (Standard)
White
Black
Bronze
Custom colors available
display cabinets
kitchen countertop
